View mmg35cb120x6tc datasheet:

MMG35CB120X6TC1200V 35A Six-Pack ModuleNovember 2020 Version 01 RoHS CompliantPRODUCT FEATURES IGBT CHIP(Trench+FS) Substrate for Low Thermal Resistance Low saturation voltage and positive temperature coefficient Fast switching and short tail current Free wheeling diodes with fast and soft reverse recovery Solder Contact Technology, Rugged mounting due to integratedMounting clamps Temperature sense includedAPPLICATIONS 2020.12.1 Motion/servo control Inverter and power suppliesIGBT-ABSOLUTE MAXIMUM RATINGS(T =25C unless otherwise specified)CSymbol Parameter/Test Conditions ValuesUnitVCES TJ=25 1200Collector Emitter VoltageVVGESGate Emitter Voltage 20TC=25, TJmax=175 54IC DC Collector CurrentTC=100, TJmax=175 35 AICMRepetitive Peak Collector Current tp=1ms 70Ptot TC
