View mmg400d120uk6hn datasheet:
MMG400D120UK6HN 1200V 400A IGBT Module December 2011 PRELIMINARY RoHS Compliant FEATURES High short circuit capability,self limiting short circuit current IGBT CHIP(T4 Fast Trench+Field Stop technology) VCE(sat) with positive temperature coefficient Fast switching and short tail current Free wheeling diodes with fast and soft reverse recovery Low switching losses TVj max =175C APPLICATIONS High frequency switching application Medical applications Motion/servo control UPS systems ABSOLUTE MAXIMUM RATINGS TC=25C unless otherwise specified Symbol Parameter Test Conditions Values UnitIGBT VCES Collector - Emitter Voltage TVj=25C 1200 VVGES Gate - Emitter Voltage 20 V600 ATC=25C IC DC Collector Current TC=80C 400 AICM Repetitive Peak Collector Current tp=1ms 800 APtot Power Dissipati
