View mrf183rev6 datasheet:

MOTOROLAOrder this documentSEMICONDUCTOR TECHNICAL DATAby MRF183/DThe RF MOSFET LineRF PowerMRF183Field Effect TransistorsMRF183SNChannel EnhancementMode LateralMOSFETsDesigned for broadband commercial and industrial applications at frequen-cies to 1.0 GHz. The high gain and broadband performance of these devices45 W, 1.0 GHzmakes ithem ideal for largesignal, common source amplifier applications in 28 LATERAL NCHANNELBROADBAND volt base station equipment.RF POWER MOSFETs Guaranteed Performance at 945 MHz, 28 VoltsOutput Power 45 Watts PEPPower Gain 11.5 dBEfficiency 33%IMD 28 dBcD Characterized with Series Equivalent LargeSignal Impedance Parameters SParameter Characterization at High Bias LevelsCASE 360B01, STYLE 1 Excellent Thermal Stability(MRF183) 100% Tested for Load Mi
