View mrf184rev2 datasheet:

MOTOROLAOrder this documentSEMICONDUCTOR TECHNICAL DATAby MRF184/DThe RF MOSFET LineMRF184RF POWER Field-Effect TransistorsMRF184SNChannel EnhancementMode Lateral MOSFETsDesigned for broadband commercial and industrial applications at frequen-cies to 1.0 GHz. The high gain and broadband performance of these devices 60 W, 1.0 GHzmakes them ideal for largesignal, common source amplifier applications in 28 LATERAL NCHANNELvolt base station equipment. BROADBANDRF POWER MOSFETs Guaranteed Performance @ 945 MHz, 28 VoltsOutput Power = 60 WattsPower Gain = 11.5 dBEfficiency = 53% Characterized with Series Equivalent LargeSignalDImpedance Parameters SParameter Characterization at High Bias LevelsCASE 360B01, STYLE 1 Excellent Thermal Stability(MRF184) Capable of Handling 30:1 VSWR @ 28 Vdc, 945 MHzGCAS
