View nce15td60bf datasheet:

Pb Free ProductNCE15TD60BF600V, 15A, Trench FS II Fast IGBTGeneral DescriptionUsing NCE's proprietary trench design and advanced FS (Field Stop) secondgeneration technology, the 600V Trench FSII IGBT offers superior conduction andswitching performances, and easy parallel operation;Features Trench FSII Technology offering Very low VCE(sat) High speed switching Positive temperature coefficient in VCE(sat) Very tight parameter distribution High ruggedness, temperature stable behaviorSchematic diagramApplication Air Condition Inverters Motor drivesPackage Marking and Ordering InformationDevice Device Package Device MarkingNCE15TD60BF TO-220F-3L NCE15TD60BFTO-220F-3LAbsolute Maximum Ratings (T =25C unless otherwise noted)CSymbol Parameter Value UnitsV Collector-Emitter Voltage 600 VCESV Gate- Emitter V
