View ncep85t25 datasheet:
Pb Free Producthttp://www.ncepower.comNCEP85T25NCE N-Channel Super Trench Power MOSFETDescriptionThe NCEP85T25 uses Super Trench technology that isuniquely optimized to provide the most efficient highfrequency switching performance. Both conduction andswitching power losses are minimized due to an extremelylow combination of R and Q . This device is ideal forDS(ON) ghigh-frequency switching and synchronous rectification.Schematic diagramGeneral Features V =85V,I =250ADS DR =2.2m (typical) @ V =10VDS(ON) GS Excellent gate charge x R productDS(on) Very low on-resistance RDS(on) 175 C operating temperature Pb-free lead platingMarking and pin assignment 100% UIS testedApplication DC/DC ConverterIdeal for high-frequency switching and synchronousrectification100% UIS TESTED!TO-220-3L top view100% V
