View ncv8403a datasheet:

ncv8403ancv8403a

NCV8403, NCV8403ASelf-Protected Low SideDriver with Temperatureand Current Limit42 V, 14 A, Single N-Channel, SOT-223http://onsemi.comNCV8403/A is a three terminal protected Low-Side Smart DiscreteVDSS ID MAXdevice. The protection features include overcurrent, overtemperature,RDS(on) TYP(Clamped) (Limited)ESD and integrated Drain-to-Gate clamping for overvoltage protection.This device offers protection and is suitable for harsh automotive42 V 53 mW @ 10 V 15 Aenvironments.DrainFeatures Short Circuit ProtectionOvervoltage Thermal Shutdown with Automatic RestartGateProtectionInput Over Voltage Protection Integrated Clamp for Inductive SwitchingESD Protection ESD Protection dV/dt RobustnessTemperature Current Current Analog Drive Capability (Logic Level Input)Limit Limit Sense AEC-Q101 Qualified and PPA
