View ncv8440a datasheet:

ncv8440ancv8440a

NCV8440, NCV8440AProtected Power MOSFET2.6 A, 52 V, N-Channel, Logic Level,Clamped MOSFET w/ ESD ProtectionFeatureshttp://onsemi.com Diode Clamp Between Gate and Source ESD Protection - Human Body Model 5000 VVDSSRDS(ON) TYP ID MAX(Clamped) Active Over-Voltage Gate to Drain Clamp Scalable to Lower or Higher RDS(on)52 V 95 mW @ 10 V 2.6 A Internal Series Gate ResistanceDrain (Pins 2, 4) These are Pb-Free DevicesBenefitsOvervoltage High Energy Capability for Inductive LoadsGateProtection(Pin 1) Low Switching Noise GenerationApplicationsESD Protection Automotive and Industrial Markets:Solenoid Drivers, Lamp Drivers, Small Motor Drivers NCV Prefix for Automotive and Other Applications Requiring SiteSource (Pin 3)and Control ChangesMARKINGDIAGRAMDRAIN4SOT-223AYWCASE 318Exxxxx GSTYLE
