View ncv8450a datasheet:

ncv8450ancv8450a

NCV8450, NCV8450ASelf-Protected High SideDriver with Temperatureand Current LimitThe NCV8450/A is a fully protected High-Side Smart Discretedevice with a typical RDS(on) of 1.0 W and an internal current limit ofhttp://onsemi.com0.8 A typical. The device can switch a wide variety of resistive,inductive, and capacitive loads. MARKINGDIAGRAMFeatures Short Circuit ProtectionAYW Thermal Shutdown with Automatic RestartSOT-223XXXXXG Overvoltage Protection(TO-261)GCASE 318E Integrated Clamp for Inductive Switching1 Loss of Ground ProtectionXXXXX = V8450 or 8450A ESD ProtectionA = Assembly Location Slew Rate Control for Low EMIY = YearW = Work Week Very Low Standby CurrentG = Pb-Free Package NCV Prefix for Automotive and Other Applications Requiring(Note: Microdot may be in either location)Unique Site
