View ndf04n60z ndp04n60z ndd04n60z datasheet:

ndf04n60z_ndp04n60z_ndd04n60zndf04n60z_ndp04n60z_ndd04n60z

NDF04N60Z, NDP04N60Z,NDD04N60ZN-Channel Power MOSFET1.8 W, 600 VoltsFeatureshttp://onsemi.com Low ON Resistance Low Gate Charge 100% Avalanche TestedVDSS RDS(ON) (TYP) @ 2 A These Devices are Pb-Free and are RoHS Compliant600 V1.8 Applications Adapter (Notebook, Printer, Gaming) LCD Panel Power Lighting Ballasts4ABSOLUTE MAXIMUM RATINGS (TC = 25C unless otherwise noted)4Rating Symbol NDF NDD/NDP UnitDrain-to-Source Voltage VDSS 600 (Note 1) V21 11 122 2 3Continuous Drain Current ID 4.0 (Note 2) A33 3DPAKTO-220FP TO-220AB IPAKContinuous Drain Current ID 2.7 (Note 2) ACASE 369AACASE 221D CASE 221A CASE 369DTA = 100CSTYLE 2STYLE 1 STYLE 5 STYLE 2Pulsed Drain Current, VGS @ 10V IDM 14 (Note 2) APower Dissipation (Note 1) PD 28 95 WMARKING DIAGRAMSGate-to-Source Voltage VGS 30 V
