View njw0281g njw0302g datasheet:

NJW0281G (NPN)NJW0302G (PNP)Preferred DevicesComplementary NPN-PNPPower Bipolar TransistorsThese complementary devices are lower power versions of thepopular NJW3281G and NJW1302G audio output transistors. Withhttp://onsemi.comsuperior gain linearity and safe operating area performance, thesetransistors are ideal for high fidelity audio amplifier output stages and15 AMPERESother linear applications.COMPLEMENTARY SILICONFeaturesPOWER TRANSISTORS Exceptional Safe Operating Area250 VOLTS, 150 WATTS NPN/PNP Gain Matching within 10% from 50 mA to 3 A Excellent Gain LinearityMARKING High BVCEO DIAGRAM High Frequency These are Pb-Free DevicesNJWxxxGBenefitsAYWW Reliable Performance at Higher Powers Symmetrical Characteristics in Complementary ConfigurationsTO-3P Accurate Reproduction of Input Signal CASE 340
