View ntmfs6h800nl datasheet:

NTMFS6H800NLPower MOSFETSingle N-Channel, 80 V, 1.9 mW, 224 AFeatures Small Footprint (5x6 mm) for Compact Design Low RDS(on) to Minimize Conduction Losseswww.onsemi.com Low QG and Capacitance to Minimize Driver Losses These Devices are Pb-Free and are RoHS CompliantV(BR)DSS RDS(ON) MAX ID MAXMAXIMUM RATINGS (TJ = 25C unless otherwise noted)Parameter Symbol Value Unit 1.9 mW @ 10 V80 V 224 ADrain-to-Source Voltage VDSS 80 V2.4 mW @ 4.5 VGate-to-Source Voltage VGS 20 VContinuous Drain TC = 25C ID 224 ACurrent RqJC D (5,6)TC = 100C 158(Notes 1, 3)SteadyStatePower Dissipation TC = 25C PD 214 WRqJC (Note 1)TC = 100C 107G (4)Continuous Drain TA = 25C ID 30 ACurrent RqJA TA = 100C 21(Notes 1, 2, 3)SteadyS (1,2,3)StatePower Dissipation TA = 25C PD 3.9 WRqJA (Notes 1, 2) N-CHANNEL MOSFETTA =
