Ordering number : ENA2294A PCP1403 N-Channel Power MOSFEThttp://onsemi.com 60V, 4.5A, 117m, Single PCP Features On-resistance RDS(on)1=92m(typ.) 4V drive Protection Diode in Halogen free compliance Specifications Absolute Maximum Ratings at Ta = 25C Parameter Symbol Conditions Value UnitDrain to Source Voltage VDSS 60 V Gate to Source Voltage VGSS 20 V Drain Current (DC) ID 4.5 A Drain Current (Pulse) IDP PW10s, duty cycle1% 18 ATc=25C 3.5 WPower Dissipation PD When mounted on ceramic substrate (600mm20.8mm) 1.3 WJunction Temperature Tj 150 C Storage Temperature Tstg - 55 to +150 C Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed,damage may occur and reliability may be affected.Ther
