View pmbt2907a datasheet:

PMBT2907A60V, 600 mA, PNP switching transistor6 March 2015 Product data sheet1. General descriptionPNP switching transistor in a small SOT23 (TO-236AB) Surface-Mounted Device (SMD)plastic package.NPN complement: PMBT2222A40V variant: PMBT29072. Features and benefits Single general-purpose switching transistor AEC-Q101 qualified3. Applications Switching and linear amplification4. Quick reference dataTable 1. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVCEO collector-emitter open base - - -60 VvoltageIC collector current - - -600 mAhFE DC current gain VCE = -10 V; IC = -150 mA; 100 - 300Tamb = 25 C5. Pinning informationTable 2. Pinning informationPin Symbol Description Simplified outline Graphic symbol31 B base C2 E emitterB3 C collectorEsym1321 2TO-236AB (SOT23)NexperiaPMBT2907A60V, 60
