View pz2n7002m datasheet:

PZ2N7002MN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID2 @VGS = 10V60V 300mASOT-23(S)ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage 60VVGSGate-Source Voltage 25TC = 25 C300IDContinuous Drain Current mATC = 100 C190IDM1 APulsed Drain Current1TC = 25 C0.35PDPower Dissipation WTC = 100 C0.14TJ, TSTGOperating Junction & Storage Temperature Range -40 to 150 CTHERMAL RESISTANCE RATINGSTHERMAL RESISTANCE SYMBOL TYPICAL MAXIMUM UNITSJunction-to-Ambient RqJA 350 C / W1Pulse width limited by maximum junction temperature.REV 1.2 1 2015/5/6PZ2N7002MN-Channel Enhancement Mode MOSFETELECTRICAL CHARACTERISTICS (TJ = 25 C, Unless Otherwise Noted)LIMITSPARAMETER SYMBOL TEST CONDITIONS
