View qm2414v datasheet:

qm2414vqm2414v

QM2414V N-Ch 20V Fast Switching MOSFETsGeneral Description Product SummeryThe QM2414V is the highest performance trench N-ch MOSFETs with extreme high cell density , BVDSS RDSON ID which provide excellent RDSON and gate charge 20V 50m 3.8Afor most of the small power switching and load switch applications. Applications The QM2414V meet the RoHS and Green Product requirement with full function reliability approved. High Frequency Point-of-Load Synchronous s Small power switching for MB/NB/UMPC/VGA Networking DC-DC Power System Features Load Switch Advanced high cell density Trench technology TSOP6 Pin Configuration Super Low Gate Charge Excellent Cdv/dt effect decline Green Device Available Absolute Maximum Ratings Symbol Parameter Rating Units VDS Drain-Source Voltage 20 V VGS Gate-Source Voltage 12 V ID@TA=25 Contin
