View qm2417c1 datasheet:

qm2417c1qm2417c1

QM2417C1 P-Ch 20V Fast Switching MOSFETsGeneral Description Product SummeryThe QM2417C1 is the highest performance trench P-ch MOSFETs with extreme high cell density , BVDSS RDSON ID which provide excellent RDSON and gate charge -20V 240m -1Afor most of the small power switching and load switch applications. Applications The QM2417C1 meet the RoHS and Green Product requirement with full function reliability High Frequency Point-of-Load Synchronous s approved. Small power switching for MB/NB/UMPC/VGA Networking DC-DC Power System Features Load Switch Advanced high cell density Trench technology SOT363 (SC-70-6L ) Pin Configuration Super Low Gate Charge Excellent Cdv/dt effect decline Green Device Available Absolute Maximum Ratings Symbol Parameter Rating Units VDS Drain-Source Voltage -20 V VGS Gate-Source Voltage 12 V
