View qm2n7002e3k1 datasheet:

qm2n7002e3k1qm2n7002e3k1

QM2N7002E3K1 N-Ch 60V Fast Switching MOSFETsGeneral Description Product SummeryThe QM2N7002E3K1 is the highest performance trench N-CH MOSFETs with extreme high cell BVDSS RDSON ID density , which provide excellent RDSON and gate 60V 3 180mAcharge for most of the small power switching and load switch applications. Applications The QM2N7002E3K1 meet the RoHS and Green Product requirement with full function reliability High Frequency Point-of-Load Synchronous approved. Buck Converter for MB/NB/UMPC Networking DC-DC Power System Features Load Switch High-speed switching SOT23S Pin Configuration Green Device Available D ESD Protected:2KV S G Absolute Maximum Ratings Symbol Parameter Rating Units VDS Drain-Source Voltage 60 V VGS Gate-Source Voltage 20 V ID@TA=25 Continuous Drain Current, VGS @ 10V1 180 mA ID@TA=70
