R6535ENZDatasheetNch 650V 35A Power MOSFETlOutlinel TO-3PFVDSS 650VRDS(on)(Max.) 0.115ID 35APD 102W lFeaturesllInner circuitl1) Low on-resistance2) Fast switching speed3) Parallel use is easy4) Pb-free plating ; RoHS compliantlApplicationllPackaging specificationslSwitching Packing Tube Packing code C17 Marking R6535ENZ Quantity (pcs) 300lAbsolute maximum ratings (Ta = 25C ,unless otherwise specified)lParameter Symbol Value UnitVDSSDrain - Source voltage 650 VContinuous drain current (Tc = 25C) ID*135 AIDP*2Pulsed drain current 105 Astatic 20 VVGSSGate - Source voltageAC(f1Hz) 30 VIASAvalanche current, single pulse 6.6 AEAS*3Avalanche energy, single pulse 867 mJPower dissipation (Tc = 25C) PD102 WTjJunction temp
