Preliminary Datasheet RJK4512DPP-E0 R07DS1010EJ0100450V - 14A - MOS FET Rev.1.00High Speed Power Switching Feb 12, 2013Features Low on-resistance RDS(on) = 0.43 typ. (at ID = 7 A, VGS = 10 V, Ta = 25C) Low leakage current High speed switching Outline RENESAS Package code: PRSS0003AG-A(Package name: TO-220FP)D1. Gate2. DrainG3. Source1S23Absolute Maximum Ratings (Ta = 25C) Item Symbol Ratings UnitDrain to source voltage VDSS 450 VGate to source voltage VGSS 30 VDrain current ID 14 ADrain peak current ID (pulse)Note1 42 ABody-drain diode reverse drain current IDR 14 ABody-drain diode reverse drain peak current IDR (pulse)Note1 42 AAvalanche current IAPNote3 3 AAvalanche energy EARNote3 0.5 mJChannel dissipation Pch Note2 30 WChannel to case thermal impedance ch-c 4.17 C/W Channel tem
