View s8550 s8550-l s8550-h s8550-j datasheet:

S8550 SOT-23 PNP Transistors321.Base2.EmitterFeatures1 3.CollectorCollector current: IC-=0.5A Simplified outline(SOT-23) Absolute Maximum Ratings Ta = 25Parameter Symbol Rating UnitCollector-Base Voltage VCBO -40 VCollector-Emitter Voltage VCEO -25 VEmitter-Base Voltage VEBO -5 VCollector Current -Continuous IC -0.5 ACollector Power Dissipation PC 0.3 WJunction Temperature Tj 150Storage Temperature Tstg -55 to 150Electrical Characteristics Ta = 25Parameter Symbol Testconditions Min Typ Max UnitCollector-base breakdown voltage VCBO IC=-100 A, IE=0 -40 VCollector-emitter breakdown voltage VCEO IC=-1mA, IB=0 -25 VEmitter-base breakdown voltage VEBO IE=-100 A, IC=0 -5 VCollector cut-off current ICBO VCB=-40V, IE=0 -0.1 ACollector cut-off current ICEO VCE=-20V, IB=0 -1 AEmitter cut-off current IEBO VEB=-3V, IC=0 -0.1 AVCE=-1V, IC=-50
