View s9018 datasheet:

S9018 SOT-23 Transistor(NPN)SOT-231. BASE 2. EMITTER 3. COLLECTOR Features AM/FM Amplifier, Local Oscillator of FM/VHF Tuner High Current Gain Bandwidth Product fT=1.1 GHz (Typ) MARKINGJ8 Dimensions in inches and (millimeters)MAXIMUM RATINGS (TA=25 unless otherwise noted) Symbol Parameter Value UnitsVCBO Collector-Base Voltage 30 V VCEO Collector-Emitter Voltage 15 V VEBO Emitter-Base Voltage 5 V IC Collector Current -Continuous 50 mA PC Collector Power Dissipation 200 mW Tj Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Tamb=25 unless otherwise specified) Parameter Symbol Test conditions MIN TYP MAX UNITCollector-base breakdown voltage V(BR)CBO 30 VIC= 100A, IE=0 Collector-emitter breakdown voltage V(BR)CEO IC= 1mA, IB=0 15 VEmitter-base breakdown voltage V(BR)EBO 5 VIE=10
