View s9018 to-92 datasheet:

S9018(NPN)TO-92 Bipolar Transistors 1. TO-92EMITTER 2. BASE 3. COLLECTOR Features High Current Gain Bandwidth Product fT=1.1 GHz (Typ) MAXIMUM RATINGS (TA=25 unless otherwise noted) Symbol Parameter Value UnitsVCBO Collector-Base Voltage 25 V VCEO Collector-Emitter Voltage 18 V VEBO Emitter-Base Voltage 4 V Dimensions in inches and (millimeters)IC Collector Current -Continuous 50 mA PC Collector Power Dissipation 0.4 W Tj Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Tamb=25 unless otherwise specified) Parameter Symbol Test conditions MIN TYP MAX UNIT Collector-base breakdown voltage V(BR)CBO IC= 100A, IE=0 25 VCollector-emitter breakdown voltage V(BR)CEO IC= 0. 1mA, IB=0 18 VEmitter-base breakdown voltage V(BR)EBO IE= 100A, IC=0 4 VCollector cut-off current ICBO VCB= 20
