View s9018l s9018h datasheet:

RUMW UMW S9018SOT-23 Plastic-Encapsulate TransistorsSOT-23 S9018 TRANSISTOR (NPN) FEATURES AM/FM Amplifier, Local Oscillator of FM/VHF Tuner 1. BASE 2. EMITTER High Current Gain Bandwidth Product 3. COLLECTOR MARKINGJ8 MAXIMUM RATINGS (Ta=25 unless otherwise noted) Symbol Parameter Value UnitVCBO Collector-Base Voltage 30 V VCEO Collector-Emitter Voltage 15 V VEBO Emitter-Base Voltage 5 V IC Collector Current -Continuous 50 mA PC Collector Power Dissipation 200 mW Thermal Resistance from Junction to Ambient 625 /W Tj Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Ta=25 unless otherwise specified) Parameter Symbol Test conditions Min Typ Max UnitCollector-base breakdown voltage V(BR)CBO 30 VIC= 100A, IE=0 Collector-emitter breakdown voltage V(BR)CEO IC= 1mA, IB
