View sbc337 datasheet:

SBC337NPN Silicon TransistorDescriptions PIN Connection High current application C Switching application BFeatures Suitable for AF-Driver stage and low E power output stages Complementary pair with SBC327 TO-92 Ordering Information Type NO. Marking Package Code SBC337 SBC337 TO-92 Absolute maximum ratings (Ta=25C) Characteristic Symbol Ratings UnitCollector-Base voltage VCBO 50 VCollector-Emitter voltage VCEO 35 VEmitter-Base voltage VEBO 5 VCollector current IC 800 mACollector dissipation PC 625 mWJunction temperature Tj 150 C Storage temperature Tstg -55~150 C Electrical Characteristics (Ta=25C) Characteristic Symbol Test Condition Min. Typ. Max. UnitCollector-Emitter breakdown voltage BVCEO IC=1mA, IE=0 35 - - VBase-Emitter turn on voltage VBE(ON) VCE=1V, IC=300mA - - 1.2 VCollector-Emitter satu
