View sbc548 datasheet:

SBC548NPN Silicon TransistorDescriptions PIN Connection General purpose application C Switching application BFeatures High voltage : VCEO=30V E Complementary pair with SBC558 TO-92 Ordering Information Type NO. Marking Package Code SBC548 SBC548 TO-92 Absolute maximum ratings (Ta=25C) Characteristic Symbol Ratings UnitCollector-Base voltage VCBO 30 VCollector-Emitter voltage VCEO 30 VEmitter-Base voltage VEBO 5 VCollector current IC 100 mACollector dissipation PC 625 mWJunction temperature Tj 150 C Storage temperature Tstg -55~150 C Electrical Characteristics (Ta=25C) Characteristic Symbol Test Condition Min. Typ. Max. UnitCollector-Emitter breakdown voltage BVCEO IC=1mA, IB=0 30 - - VBase-Emitter turn on voltage VBE(ON) VCE=5V, IC=2mA 550 - 700 mVBase-Emitter saturation voltage VBE(sat) IC=100mA, IB
