View sgp10n60a sgw10n60a rev2 datasheet:

SGP10N60A SGW10N60AFast IGBT in NPT-technology C 75% lower Eoff compared to previous generation combined with low conduction losses G Short circuit withstand time 10 s E Designed for: - Motor controls - Inverter PG-TO-247-3 NPT-Technology for 600V applications offers: - very tight parameter distribution - high ruggedness, temperature stable behaviour - parallel switching capability PG-TO-220-3-1 Qualified according to JEDEC1 for target applications Pb-free lead plating; RoHS compliant Complete product spectrum and PSpice Models : http://www.infineon.com/igbt/ Type VCE IC VCE(sat) Tj Marking PackageSGP10N60A 600V 10A 2.3V G10N60A PG-TO-220-3-1150C SGW10N60A 600V 10A 2.3V G10N60A PG-TO-247-3150C Maximum Ratings Parameter Symbol Value UnitCollector-emitter voltage VCE 600 VDC collector curren
