View sgp20n60 sgw20n60 datasheet:

SGP20N60 SGW20N60Fast IGBT in NPT-technology C 75% lower Eoff compared to previous generation combined with low conduction losses Short circuit withstand time 10 s G Designed for: E- Motor controls - Inverter NPT-Technology for 600V applications offers: - very tight parameter distribution - high ruggedness, temperature stable behaviour - parallel switching capability PG-TO-220-3-1 PG-TO-247-3 Qualified according to JEDEC1 for target applications Pb-free lead plating; RoHS compliant Complete product spectrum and PSpice Models : http://www.infineon.com/igbt/ Type VCE IC VCE(sat) Tj Marking PackageSGP20N60 600V 20A 2.4V G20N60 PG-TO-220-3-1150C SGW20N60 600V 20A 2.4V G20N60 PG-TO-247-3150C Maximum Ratings Parameter Symbol Value UnitCollector-emitter voltage VCE 600 VDC collector current IC A 4
