View sgs10n60ruf datasheet:

April 2001 IGBTSGS10N60RUFShort Circuit Rated IGBTGeneral Description FeaturesFairchild's RUF series of Insulated Gate Bipolar Transistors Short circuit rated 10us @ TC = 100C, VGE = 15V(IGBTs) provide low conduction and switching losses as High speed switchingwell as short circuit ruggedness. The RUF series is Low saturation voltage : VCE(sat) = 2.2 V @ IC = 10Adesigned for applications such as motor control, High input impedanceuninterrupted power supplies (UPS) and general inverterswhere short circuit ruggedness is a required feature.ApplicationAC & DC Motor controls, general purpose inverters, robotics, servo controls CCGGTO-220FEEG C E Absolute Maximum Ratings TC = 25C unless otherwise notedSymbol Description SGS10N60RUF UnitsVCES Collector-Emitter Voltage 600 VVGES Gate-Emitter Voltage 20 VCollector Curre
