View sihp18n50c datasheet:

sihp18n50csihp18n50c

SiHP18N50CVishay SiliconixPower MOSFETFEATURESPRODUCT SUMMARY Low Figure-of-Merit Ron x QgVDS (V) at TJ max. 560 100 % Avalanche TestedRDS(on) ()VGS = 10 V 0.225 High Peak Current CapabilityQg (Max.) (nC) 76 dV/dt RuggednessQgs (nC) 21Qgd (nC) 29 Improved trr/QrrConfiguration Single Improved Gate ChargeD High Power Dissipations Capability Compliant to RoHS Directive 2002/95/ECTO-220ABGSDSGN-Channel MOSFET ORDERING INFORMATIONPackage TO-220ABLead (Pb)-free SiHP18N50C-E3ABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)PARAMETER SYMBOL LIMIT UNITDrain-Source Voltage VDS 500V Gate-Source Voltage VGS 30TC = 25 C 18Continuous Drain Current (TJ = 150 C)a VGS at 10 V IDTC = 100 C 11 APulsed Drain Currentb IDM 72Linear Derating Factor TO-220AB 1.8 W/C Single Pulse Av
