View spd03n60c3 datasheet:

spd03n60c3spd03n60c3

isc N-Channel MOSFET Transistor SPD03N60C3,ISPD03N60C3FEATURESStatic drain-source on-resistance:RDS(on)1.4Enhancement mode:100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationDESCRITIONHigh peak current capabilityImproved transconductanceABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 600 VDSSV Gate-Source Voltage 20 VGSI Drain Current-Continuous 3.2 ADI Drain Current-Single Pulsed 9.6 ADMP Total Dissipation @T =25 38 WD CT Max. Operating Junction Temperature 150 jT Storage Temperature -55~150 stgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNITChannel-to-case thermal resistance/WRth(j-c) 3.3Channel-to-ambient thermal resistance/WRth(j-a) 751isc websitewww.iscsemi.cn isc & iscsemi i
