View spn3400s23rg datasheet:

SPN3400S23RGwww.VBsemi.twN-Channel 30-V (D-S) MOSFETFEATURESPRODUCT SUMMARY Halogen-free According to IEC 61249-2-21VDS (V) RDS(on) ()ID (A)a Qg (Typ.)Definition0.030 at VGS = 10 V TrenchFET Power MOSFET6.530 4.5 nC 100 % Rg Tested0.033 at VGS = 4.5 V 6.0 Compliant to RoHS Directive 2002/95/ECAPPLICATIONS DC/DC ConverterDTO-236(SOT-23)G 1G3 DS 2STop ViewN-Channel MOSFETABSOLUTE MAXIMUM RATINGS TA = 25 C, unless otherwise notedParameter Symbol Limit UnitVDSDrain-Source Voltage 30VGate-Source Voltage VGS 20TC = 25 C6.5aTC = 70 C 6.0Continuous Drain Current (TJ = 150 C) IDTA = 25 C5.3ATA = 70 C 5.0Pulsed Drain Current IDM25TC = 25 C 1.4ISContinuous Source-Drain Diode Current TA = 25 C0.9b, cTC = 25 C1.7TC = 70 C 1.1PDMaximum Power Dissipati
