View sqp90142e datasheet:
SQP90142Ewww.vishay.comVishay SiliconixAutomotive N-Channel 200 V (D-S) 175 C MOSFETFEATURESTO-220AB TrenchFET power MOSFET Package with low thermal resistance AEC-Q101 qualified 100 % Rg and UIS tested Material categorization: for definitions of compliance please seewww.vishay.com/doc?99912SSDGDTop ViewPRODUCT SUMMARYGVDS (V) 200RDS(on) () at VGS = 10 V 0.0153ID (A) 78.5N-Channel MOSFET SConfiguration SinglePackage TO-220ABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)PARAMETER SYMBOL LIMIT UNITDrain-source voltage VDS 200V Gate-source voltage VGS 20TC = 25 C 78.5Continuous drain current IDTC = 125 C 45Continuous source current (diode conduction) a IS 120 APulsed drain current b IDM 170Single pulse avalanche current IAS 64L = 0.1 mHSingle pulse avalanche energy EAS
