View sqp90p06-07l datasheet:

sqp90p06-07lsqp90p06-07l

SQP90P06-07Lwww.vishay.comVishay SiliconixAutomotive P-Channel 60 V (D-S) 175 C MOSFETFEATURESPRODUCT SUMMARY TrenchFET power MOSFETVDS (V) -60 Package with low thermal resistanceRDS(on) () at VGS = -10 V 0.0067 AEC-Q101 qualified dRDS(on) () at VGS = -4.5 V 0.0088 100 % Rg and UIS testedID (A) -120 Material categorization:Configuration SingleFor definitions of compliance please seewww.vishay.com/doc?99912 TO-220ABSGSSDDGTop ViewP-Channel MOSFETORDERING INFORMATIONPackage TO-220Lead (Pb)-free and Halogen-free SQP90P06-07L-GE3ABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)PARAMETER SYMBOL LIMIT UNITDrain-Source Voltage VDS -60V Gate-Source Voltage VGS 20TC = 25 C a -120IDContinuous Drain Current aTC = 125 C -87IS -120 AContinuous Source Current (Diode Conductio
