View ss8050 datasheet:

SS8050NPN GENERAL PURPOSE SWITCHING TRANSISTOR25Volts POWER 300mWattsVOLTAGEFEATURESNPN epitaxial silicon, planar design. Collector-emitter voltage VCE=25V.Collector current IC=1.5A.ansition frequency fT>100MHz @ TrIC=50mAdc, VCE=10Vdc, f=30MHz.In compliance with EU RoHS 2002/95/EC directives.MECHANICAL DATACase: SOT-23, Plastic3Terminals: Solderable per MIL-STD-750, Cmethod 2026 Y1Approx. Weight: 0.008gramMarking:Y1B E1 2RANK L H JRANGE 120-200 200-350 300-400MAXIMUM RATINGS(Ta=25 unless otherwise noted)Symbol Parameter Vaule UnitVCBO Collector-Base Voltage 40 VVCEO Collector-Emitter Voltage 25 VVEBO Emitter-Base Voltage 5 VIC Collector Current 1.5 APC Total Device Dissipation 0.3 WORJA Thermal Resistance Form Junction to Ambient 625 C/WOTJ Junction Temperature 150 COTSTG Storage Temperat
