View ss8550 datasheet:

March 2008SS85502W Output Amplifier of Portable Radios in Class B Push-pull OperationFeatures Complimentary to SS8050 Collector Current: IC=1.5A Collector Power Dissipation: PC=1W (TC=25C)TO-9211. Emitter 2. Base 3. CollectorAbsolute Maximum Ratings Ta=25C unless otherwise noted Symbol Parameter Ratings UnitsVCBO Collector-Base Voltage -40 VVCEO Collector-Emitter Voltage -25 VVEBO Emitter-Base Voltage -6 VIC Collector Current -1.5 APC Collector Power Dissipation 1 WTJ Junction Temperature 150 CTSTG Storage Temperature -65 ~ 150 CElectrical Characteristics Ta=25C unless otherwise noted Symbol Parameter Test Condition Min. Typ. Max. UnitsBVCBO Collector-Base Breakdown Voltage IC= -100A, IE=0 -40 VBVCEO Collector-Emitter Breakdown Voltage IC= -2mA, IB=0 -25 VBVEBO Emitter-Base Breakdown Voltage IE= -100A, IC=0 -6 VICB
