View ss8550 datasheet:

SS8550 PNP EPITAXIAL SILICON TRANSISTOR2W OUTPUT AMPLIFIER OF PORTABLETO-92RADIOS IN CLASSB PUSH-PULL OPERATION. Complimentary to SS8050 Collector Current IC= -1.5A Collector Dissipation:PC=2W (TC=25 )ABSOLUTE MAXIMUM RATINGS (T =25 )A Characteristic Symbol Rating UnitCollector-Base Voltage VCBO -40 VCollector-Emitter Voltage VCEO -25 VEmitter-Base Voltage VEBO -6 VCollector Current IC -1.5 ACollector Dissipation PC 1 WJunction Temperature TJ 150 Storage Temperature TSTG -65 ~ 150 1. Emitter 2. Base 3. CollectorELECTRICAL CHARACTERISTICS (T =25 )ACharacteristic Symbol Test Conditions Min Typ Max UnitCollector-Base Breakdown Voltage BVCBO IC= -100 , IE=0 -40 VCollector-Emitter Breakdown Voltage BVCEO IC= -2mA, IB=0 -25 VEmitter-Base Breakdown Voltage BVEBO IE= -100 , IC=0 V-6Collector Cut-off Current ICBO VCB= -35V, IE=0 -100
