View ss8550w-l ss8550w-h ss8550w-j datasheet:

SS8550WSS8550WSS8550WSS8550WTRANSISTOR(PNP)SS8 550 W SOT323 3FEATURES Complimentary to SS8050W 1. BASE 12. EMITTER 23. COLLECTOR MAXIMUM RATINGS (TA=25 unless otherwise noted) Symbol Parameter Value UnitsVCBO Collector-Base Voltage -40 VVCEO Collector-Emitter Voltage -25 VVEBO Emitter-Base Voltage -5 VIC Collector Current -Continuous -1.5 APC Collector Power Dissipation 0.2 WTj Junction Temperature 150Tstg Storage Temperature -55-150ELECTRICAL CHARACTERISTICS (Ta=25 unless otherwise specified)Parameter Symbol Test conditions MIN MAX UNITCollector-base breakdown voltage V(BR)CBO IC=-100A, IE=0 -40 VCollector-emitter breakdown voltage V(BR)CEO IC=-0.1mA, IB=0 -25 VEmitter-base breakdown voltage V(BR)EBO IE=-100A, IC=0 -5 VCollector cut-off current ICBO VCB=-40V, IE=0 -0.1 ACollector cut-off current
