STB100N10F7, STD100N10F7, STF100N10F7, STP100N10F7N-channel 100 V, 0.0068 typ., 80 A, STripFET VII DeepGATE Power MOSFET in D2PAK, DPAK, TO-220FP and TO-220Datasheet - production dataFeaturesTAB TABRDS(on) 3Order codes VDS max ID PTOT131 DPAKSTB100N10F7 80 A 120 WD2PAKSTD100N10F7 80 A 120WTAB100 V 0.008 STF100N10F7 45 A 30 WSTP100N10F7 80A 150 W33 Ultra low on-resistance2211 100% avalanche testedTO-220TO-220FPApplicationsFigure 1. Internal schematic diagram Switching applicationsD(2, TAB)DescriptionThese devices utilize the 7th generation of design rules of STs proprietary STripFET technology, with a new gate structure. The resulting Power G(1)MOSFET exhibits the lowest RDS(on) in all packages.S(3)AM01475v1Table 1. Device summaryOrder codes Marking Packages PackagingSTB
