View stb13007dt4 datasheet:

STB13007DT4High voltage fast-switching NPN power transistorGeneral features Improved specification: Lower leakage current, Tighter gain range, DC current gain preselection, Tighter storage time range High voltage capability Integrated free-wheeling diode3 Low spread of dynamic parameters 1 Minimum lot-to-lot spread for reliable operationD2PAK Very high switching speed(T0-263) Fully characterized at 125 C Large RBSOA In compliance with the 2002/93/EC European DirectiveInternal schematic diagramDescriptionThe device is manufactured using high voltageMulti-Epitaxial Planar technology for highswitching speeds and medium voltage capability.It uses a Cellular Emitter structure to enhanceswitching speeds.Applications Electronic transformers for halogen lamps Switch mode power suppliesOrder codesPart
