View stb13n60m2 std13n60m2 datasheet:
STB13N60M2, STD13N60M2N-channel 600 V, 0.35 typ., 11 A MDmesh II Plus low Qg Power MOSFETs in D2PAK and DPAK packagesDatasheet - production dataFeaturesOrder codes VDS @ TJmax RDS(on) max IDSTB13N60M2TAB650 V 0.38 11 ASTD13N60M2TAB33 Extremely low gate charge11 Lower RDS(on) x area vs previous generationDPAKD2PAK Low gate input resistance 100% avalanche tested Zener-protectedApplicationsFigure 1. Internal schematic diagram, TAB Switching applicationsDescriptionThese devices are N-channel Power MOSFETs developed using a new generation of MDmesh technology: MDmesh II Plus low Qg. These revolutionary Power MOSFETs associate a vertical structure to the company's strip layout to yield one of the world's lowest on-resistance and gate charge. They are therefore suitable for the most demandin
