View std15nf10t4 datasheet:

std15nf10t4std15nf10t4

INCHANGE SemiconductorIsc N-Channel MOSFET Transistor STD15NF10T4FEATURESWith To-252(DPAK) packageApplication oriented characterizationExcellent switching performance100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSSwitching applicationsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 100 VDSSV Gate-Source Voltage 20 VGSSDrain Current-Continuous@T =25C 23I AD16 T =175 T =125J CI Drain Current-Single Pulsed 92 ADMP Total Dissipation @T =25 70 WD CT Max. Operating Junction Temperature 175 chStorage Temperature -55~175 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WRth(ch-c) Channel-to-case thermal resistance 2.14/WRth(ch-a) Channel-to-ambient thermal re
