View std25nf20 datasheet:
STD25NF20Automotive-grade N-channel 200 V, 0.10 typ., 18 A STripFET Power MOSFET in a DPAK packageDatasheet - production dataFeaturesRDS(on) Order code VDS max ID PTOTSTD25NF20 200 V 0.125 18 A 110 WTAB Designed for automotive applications and 31 AEC-Q101 qualifiedDPAK Extremely low gate charge Exceptional dv/dt capability Low gate input resistance 100% avalanche testedApplicationsFigure 1. Internal schematic diagram Switching applicationsD(2, TAB)DescriptionThis N-channel enhancement mode Power MOSFET benefits from the latest refinement of STMicroelectronics' unique single feature size G(1)strip-based process, which decreases the critical alignment steps to offer exceptional manufacturing reproducibility. The result is a transistor with extremely high packing density for S(3)low on-resista
