View std2nk70z std2nk70z-1 datasheet:

STD2NK70ZSTD2NK70Z-1N-channel 700V - 6 - 1.6 A - DPAK/IPAKZener protected SuperMESH Power MOSFETGeneral featuresType VDSS RDS(on) ID PwSTD2NK70Z 700V 7 1.6A 45WSTD2NK70Z-1 700V 7 1.6A 45W3321 Extremely high dv/dt capability1 ESD improved capabilityDPAKIPAK 100% avalanche tested New high voltage benchmark Gate charge minimizedDescriptionThe SuperMESH series is obtained through an Internal schematic diagramextreme optimization of STs well established strip-based PowerMESH layout. In addition to pushing on-resistance significantly down, special care is taken to ensure a very good dv/dt capability for the most demanding application. Such series complements ST full range of high voltage MOSFETs including revolutionary MDmesh products.Applications Switching applicationOrder codesPar
