View stl18n65m5 datasheet:

STL18N65M5N-channel 650 V, 0.215 typ., 15 A MDmesh V Power MOSFET in a PowerFLAT 5x6 HV packageDatasheet - preliminary dataFeaturesOrder code VDS RDS(on)max. IDSTL18N65M5 710 V 0.240 15 A(1)1. The value is rated according to Rthj-case and limited by package.1 Outstanding RDS(on)*area23 Extremely large avalanche performance4 Gate charge minimizedPowerFLAT 5x6 HV Very low intrinsic capacitance 100% avalanche testedFigure 1. Internal schematic diagram ApplicationsD(5, 6, 7, 8) Switching applications8 7 6 5DescriptionThis device is an N-channel MDmesh V Power MOSFET based on an innovative proprietary G(4)vertical process technology, which is combined with STMicroelectronics well-known PowerMESH horizontal layout structure. The resulting product has extremely low on-1 2 3 4resistance, w
