View stp75nf75 datasheet:

stp75nf75stp75nf75

INCHANGE Semiconductorisc N-Channel MOSFET Transistor STP75NF75FEATURESDrain Current I = 80A@ T =25D CDrain Source Voltage-: V = 75V(Min)DSSStatic Drain-Source On-Resistance: R = 0.011(Max)DS(on)100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationDESCRIPTIONSuitable as primary switch in advanced high-efficiency, high-frequency isolated DC-DC converters for Telecom and Computerapplications. It is also intended for any application with low gatedrive requirements .APPLICATIONSSwitching applicationABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 75 VDSSV Gate-Source Voltage-Continuous 20 VGSI Drain Current-Continuous 80 ADI Drain Current-Single Pluse 320 ADMP Total Dissipation @T =25 300 WD CT Max. Operating Junc
