View stp75nf75fp datasheet:

stp75nf75fpstp75nf75fp

INCHANGE SemiconductorIsc N-Channel MOSFET Transistor STP75NF75FPFEATURESExcellent switching performanceWith low gate drive requirementsEasy to drive100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSSwitching applicationABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 75 VDSSV Gate-Source Voltage 20 VGSSDrain Current-Continuous@T =25C 80I AD70T =100CI Drain Current-Single Pulsed 320 ADMP Total Dissipation 45 WDT Operating Junction Temperature -55~175 jStorage Temperature -55~175 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WRth(ch-c) Channel-to-case thermal resistance 3.33/WRth(ch-a) Channel-to-ambient thermal resistance 62.51isc websitewww.iscsemi.cn isc
