View stu102s std102s datasheet:

stu102s_std102sstu102s_std102s

STU102SGreenProductSTD102SSamHop Microelectronics Corp.Ver 1.0N-Channel Logic Level Enhancement Mode Field Effect TransistorFEATURESPRODUCT SUMMARYSuper high dense cell design for low RDS(ON).VDSS ID RDS(ON) (m) MaxRugged and reliable.566 @ VGS=10VTO-252 and TO-251 Package.100V 6A734 @ VGS=4.5VGGSSSTU SERIESSTD SERIESTO-252AA(D-PAK)TO-251(I-PAK)(TC=25C unless otherwise noted)ABSOLUTE MAXIMUM RATINGSSymbol Parameter UnitsLimitVDSDrain-Source Voltage 100VVGS Gate-Source Voltage 20 VTC=25C 6 Aa cID Drain Current-ContinuousTC=70C 4.8 AcIDM A-Pulsed 17dEAS Single Pulse Avalanche Energy 2 mJTC=25C 42 WaMaximum Power DissipationPDTC=70C 27 WOperating Junction and StorageTJ, TSTG Temperature Range -55 to 150 CTHERMAL CHARACTERISTICSaRJC Thermal Resistance, Junction-to-Case 3
