View svf740t svf740f datasheet:

svf740t_svf740fsvf740t_svf740f

SVF740T/F_Datasheet 10A, 400V N-CHANNEL MOSFET GENERAL DESCRIPTION SVF740T/F is an N-channel enhancement mode power MOS field effect transistor which is produced using Silan proprietary F-cellTM structure VDMOS technology. The improved planar stripe cell and the improved guard ring terminal have been especially tailored to minimize on-state resistance, provide superior switching performance, and withstand high energy pulse in the avalanche and commutation mode. These devices are widely used in AC-DC power suppliers, DC-DC converters and H-bridge PWM motor drivers. FEATURES 10A,400V,RDS(on)(typ)=0.45 @VGS=10V Low gate charge Low Crss Fast switching Improved dv/dt capability ORDERING INFORMATION Part No. Package Marking Material Packing SVF740T TO-220-3L SVF740T Pb free Tube SVF740F TO-220F-3L SVF740F Pb free Tube ABSOLU
