View swf20n60k datasheet:

SW20N60K N-channel Enhanced mode TO-220F MOSFET Features TO-220F BVDSS : 600V ID : 20A High ruggedness Low RDS(ON) (Typ 0.15)@VGS=10V RDS(ON) : 0.15 Low Gate Charge (Typ 60nC) Improved dv/dt Capability 2 1 100% Avalanche Tested 2 3 Application:LED,Charger,PC Power 1 1. Gate 2. Drain 3. Source 3 General Description This power MOSFET is produced with advanced super junction technology of SAMWIN. This technology enable the power MOSFET to have better characteristics, including fast switching time, low on resistance, low gate charge and especially excellent avalanche characteristics. Order Codes Item Sales Type Marking Package Packaging 1 SW F 20N60K SW20N60K TO-220F TUBE Absolute maximum ratings Symbol Parameter Value Unit VDSS Drain to source voltage 600 V Continuous drain current (@TC=25oC) 20*
